Hydraulic Rubber Bale Cutter Cutting Machine SMCM-011 / / Simptek Machinery

Hydraulic Rubber Bale Cutter Cutting Machine SMCM-011

* Better quality cutting
* High-quality precision cutting
* Higher productivity
* Greater flexibility
* Excellent performance
* Replaceable cutting blade
* Anti-tiedown, dual palm controls
* Fall protection safety measure
* Powder coated frame
* Stainless steel enclosure
* Integral filter/regulator
* Designed with hydraulic oil system is more better than mechanical riven type in saving power
* Blade is made of special alloy steel in order to reduce the abrasion
* A quick method of cutting large rubber slabs/bales
* Ideal for small and large production requirements
* Easy and safy to operate , Less maintenance
* User-Friendly operation that require skilled operator
* Suitable for nature and synthetic rubber material

Description

Rubber bale cutter , also named as rubber cutting machine ,it mainly consist of motor, vane pump, magnetic exchange valve, overflow valve, slave RAM, oil pressure gauge pipe, hydro-cylinder support, rubber cutting knife, rack, conveying groove etc. The Rubber Bale Cutting Machine is a kind of rubber processing equipment,which is widely used to cut the rubber block , including natural and synthetic rubber ) into small rubber pieces ready for plasticating and mixing in kneader dispersion or banbury machine . Thus ,this rubber bale cutter is usually installed near the rubber mill and in order to cut small pieces of rubber. Each time when you are ready to cut the rubber material , just feed the raw material into the knife roller , then press the motor button in cabinet , knife will fall down and cut the material

Specification

Type	Width (mm)	Stroke (mm)	Diameter of the piston (mm)	Time Taken by the Stroke (second)	Power (KW)	Overall Dimension (LxWxH)	Weight (kg)
SMP-8	660	680	150	16~25	5.5	1900×720×2580	1500
SMP-10	1000	1000	150	10~16	7.5	2240×720×2580	1800
SMP-12	1000	1200	150	10~16	7.5	2540×750×2880	2000

How Does Rubber Bale Cutter Work?

The high-precision hydraulic-powered rubber bale cutter are used to cut rubber into pieces as per speicific needs. The rubber bales or block can be fed through the machine. These rubber piece cut travels through the rubbe bale cutter machine which ensures smooth movement. 1. Check blade is in the up position. 2. Open the gate. 3. Place slab of rubber along the cutting edge. 4. Leave the cage area and close the gate. 5. Press the cut button to lower the blade to cut the rubber slab. 6. Blade rises after the cut sequence; wait until the blade is fully up. 7. Open the gate to remove the cut pieces. 8. Repeat the cycle.

A Wide Of Application

The Simptek Rubber Bale Cutter is very flexible and is is used for cutting all kinds of large sized natural rubber or synthetic rubber products, such as large plastic tubes, film, rubber lumps, and sheet materials , it is also very applicable for other plastic ,polymer,silicone including: Silicone Nitrile Bale NBR FKM CR HNBR ACM EPDM SBR EVA Bench bale cutter Slicing type Cross blade type And many more…
